| Physical | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Dish Diameter | 64cm (25”) | |||||||||||
| Dimension | 78 X 80 cm | |||||||||||
| Weight | 37 KG | |||||||||||
| Technical Specifications | ||||||||||||
| Frequency | Ku Band(10.7~12.75GHz) | |||||||||||
| Minimum EIRP | 46dBW | |||||||||||
| Operating Platform | 3-Axis Stabilized (Azimuth, Elevation, Cross-level) and 4-Axis Tracking(Skew angle) | |||||||||||
| Polarization | Linear or Circular | |||||||||||
| Elevation Angle | -5°~115° | |||||||||||
| Azimuth Range | 690° | |||||||||||
| Cross-level Angle | ±35° | |||||||||||
| Ship Motion | Roll±25° Pitch±15° Yaw±8°@6 sec period | |||||||||||
| Tracking Rate | >90°/s | |||||||||||
